Sai Steel & Engineering is one of the prominent suppliers of a few first class things, and one of them is plates which are given in a substitute extent of composites. We are the primary suppliers of this thing and the prominent producers, exporters, dealers and wholesalers of a much-mentioned thing in the overall and local market known as SA 387 GR.91 CL 2 PLATES. All things are made per the client’s requirements to fulfill their solicitations.
Plates are comprehensively used things, and they are conveyed in numerous sorts. It is available in various tasks, conclusions, rules, grades, compounds, shapes, thicknesses, sizes, reaches, viewpoints, etc. Be that as it may, over all of the sorts of plates, SA 387 GR.91 CL2 PLATES are the most generally used appeared differently in relation to a few different plates. This pervasiveness is in light of the fact that these plates offer astounding mechanical and compound properties when used in arranged conditions.
ASME SA387 Gr.91 CL.2 BQ Steel Plate Specification :
Grade : ASME SA 387 Grade 91 CL.2 Alloy Steel Plates
Width : 1000mm-4500mm
Thickness : 5mm-150mm
Length : 3000mm -18000mm
Impact tested : -52° C
Process : Hot-Rolled (HR)
ASME SA387 GR.91 CL.2 ALLOY STEEL PLATES EQUIVALENT GRADES
| COUNTRY | USA | EUROPEAN | GERMANY | ENGLAND | FRANCE | RUSSIA |
| STANDARDS | ASME | EN 10028 | DIN | BS | AFNOR 36206 | GOST |
| Grade 91 | SA387 | 10CrMoVNb9-1 | – | – | – | – |
SA 387 GR 91 CL2 CHEMICAL COMPOSITION
| Grade | C | Mn | P | S | Si | Cr | Mo | V |
| SA 387 Gr.91 | 0.08-0.12 | 0.30-0.60 | 0.020 | 0.010 | 0.20-0.50 | 8.00-9.50 | 0.85-1.05 | 0.18-0.25 |
ASME SA387 GR 91 CL.2 ALLOY STEEL PLATES MECHANICAL PROPERTIES
| Class | Tensile (MPa) | Yield (MPa) | Elong. (50mm) | Elong. (200mm) | Reduc’n of Area* |
| Class 2 | 585 – 760 | 415 min | 18% min | – | – |
